Paper Angle Boards & Edge Protectors
Manufactured on India's pioneer automatic cutting lines, our rigid paper angle boards reinforce unitized pallet loads, prevent strap cutting, and dramatically increase vertical stacking capacity.
High-Load Performance & Structural Integrity
Rigid laminated paper edge protectors manufactured on India’s pioneer automatic cutting lines. Designed to reinforce palletized unit loads, eliminate strap-tension bite marks, and dramatically increase vertical stacking capacity in sea containers and automated warehouses, preventing package collapse and transit claims.
Key Structural Advantages:
- Continuous automatic cutting line ensuring razor-sharp 90° angle formation and uniform caliper across entire profile
- Substantially increases vertical column stacking strength, allowing pallets to be double-stacked safely in warehouses
- High resistance to extreme strap tension from automated PET and steel strapping systems
- Available in plain natural Kraft, bleached white outer liner, or custom 2-color corporate logo branding
- Water-repellent barrier coatings available for cold-chain, refrigerated storage, and high-humidity marine shipping
Engineering Specifications & Testing Rigor
Manufactured in accordance with strict millimetric tolerances, hydraulic load tests, and laboratory moisture calibrations.
| Technical Parameter | Certified Engineering Specification |
|---|---|
| SPEC.01Leg Widths (Flanges) | 25 x 25 mm up to 100 x 100 mm (Equal & Unequal leg profiles) |
| SPEC.02Caliper / Thickness | 2.0 mm to 8.0 mm heavy-duty laminated kraft plies |
| SPEC.03Length Customization | Precision cut from 50 mm (corner protector clips) up to 4,500 mm |
| SPEC.04Profile Angle | True 90° right angle profile formed under continuous compression |
| SPEC.05Print & Branding Options | Up to 2-color custom corporate branding, barcodes, and handling warnings |
| SPEC.06Adhesive Chemistry | High-tack water-soluble eco-friendly PVA bond |
| SPEC.07Moisture Barrier | Optional wax emulsion or polyethylene outer liner coating |
| SPEC.08Recyclability | 100% Biodegradable & fully recyclable paper fiber |
Engineered for High-Throughput Sectors
Trusted by multinational manufacturers, chemical exporters, and automated supply chains across India and international trade lanes.
Vertical Column Stacking
Placed at pallet corners to distribute vertical load, allowing double-stacking in trailers and ocean containers.
Strapping Bite Prevention
Prevents high-tension PET, PP, and steel strapping bands from cutting into fragile cardboard cartons.
Perimeter Framing
Heavy 8mm caliper angle boards protect sharp metallic corners and delicate architectural glass edges.
Vented Fruit & Vegetable Crates
Water-resistant coated angle boards reinforce corrugated produce boxes in chilled refrigerated containers.
Zero-Defect Manufacturing Lifecycle
From calibrated raw material screening to final hydraulic crush testing, every production phase operates under ISO 9001:2015 control.
Multi-Ply Kraft Reel Feeding
Up to 15 layers of high-tensile virgin and recycled kraft paper are unwound simultaneously.
Automated Adhesive Lamination
High-solid PVA glue is applied between plies with precision doctor blades for complete bonding.
Heated L-Profile Compression Forming
Continuous progressive forming rollers shape the laminated plies into a razor-sharp 90° right angle.
High-Speed Automated Cross-Cutting
Servo-driven automatic cutting guillotine cuts edge boards to exact millimetric lengths with clean square ends.
Frequently Asked Questions
Key technical answers for procurement heads, packaging engineers, and supply chain managers.
What leg widths and thicknesses can you manufacture?
We manufacture equal and unequal leg profiles from 25x25mm up to 100x100mm, with thicknesses from 2.0mm to 8.0mm to meet lightweight carton protection or heavy industrial machinery export requirements.
Can these angle boards withstand moisture in refrigerated sea containers?
Yes. We offer specialized water-resistant coatings and moisture-barrier outer plies engineered for cold-chain fruit, pharma, and marine cargo transit.
Can you print our corporate logo or handling warnings on the outer face?
Yes. Our automated line is equipped for in-line flexographic printing up to 2 colors with your logo, handling arrows, or company details.
Need Custom Sizing, Sample Batches, or Container Pricing for Paper Angle Boards & Edge Protectors?
Our plant engineers evaluate your exact unit load requirements, sea transit corridors, and automatic handling machinery to deliver customized blueprints and pre-shipment certificates.
